BY150MC Large Industrial Burner Eco-Friendly Industrial Burner Baltur gas burner 1.5ton boiler
BY150MC burner provides the heat necessary for converting water in the boiler into steam and is attached to the boiler.
Model: BY150MC
Brand: Baiyan
Fuel: Natural Gas,LPG
Output Power: 300-1500kw
Control Mode: two stage sliding
Applicable Power Supply: AC 400v 50Hz
Applicable Boiler: 1.5T/H
Certificate: ISO
Packaging Details:Neutral/Customized packaging
MOQ: 1pcs
Delivery terms: Sea/Air/Land
Delivery Port: Ningbo Port
Applications: All kinds of industrial boilers, drying furnaces, kilns, quenching furnaces, steam furnaces, hot water furnaces, boiling water furnaces, ovens, heating furnaces, thermal oil furnaces and other boilers.
Technical Parameters | ||||
Model | BY150P | BY140LXP | BY150MC | |
Output Power | Kw | 300-1500 | 200-1450 | 300-1500 |
Control Mode | two stage | two stages sliding | two stages sliding | |
Gas Consumption | Sm³/H | 30--150 | 20-145 | 30--150 |
Motor Power | kw | 2.2 | ||
Applicable power supply | AC400v 50Hz | |||
Safety Protection Level | IP 40 （protection level can be improved according to different requirement) | |||
NOx | ＜80 | |||
Applicable boiler | T/h | 1.5 | ||
Kw | 1035 | |||
103*kcal/h | 890 | |||
Static Pressure | Kpa | 8--12 | 8--12 | 8--12 |
Dynamic Pressure | 8--10 | 8--10 | 8--10 | |
Dimension | mm | 1050*820*700 | ||
Weight | Kg | 80 | 92 | 92 |
